RCF BS 5EN - Specifications

11
ENGLISH
SPECIFICATIONS
Input voltage:
Power (selectable):
Input impedance:
Frequency response (–10 dB):
Sensitivity (±3 dB, 1 kHz):
Max. sound pressure level:
Cabinet material:
Grille:
Colour:
Connection:
IP protection grade:
Dimensions (without bracket):
100 V
20 W – 10 W – 5 W – 2.5 W (100 V)
500 Ω (20 W)
1 kΩ (10 W)
2 kΩ (5 W)
4 kΩ (2.5 W)
100 Hz ÷ 20 kHz
88 dB (1 W, 1 m), 76 dB (1 W, 4m)
101 dB (20 W, 1 m), 89 dB (20 W, 4 m)
ABS
steel
white
ceramic screw terminals
IP 65
ø 180 mm, depth: 260 mm
