8
ENGLISH
INSTALLATION
WARNING: Make sure that the loudspeaker is installed in a stable and secure
way in order to avoid any conditions that May be dangerous for persons or
structures.
ensure the support surface (the wall) has the necessary Mechanical
characteristics to support the loudspeaker weight.
before installing the loudspeaker, carefully check all coMponents to be used and
Make sure there is no daMage, deforMation, corrosion and/or Missing or daMaged
parts that could reduce the safety of the installation.
BS 5EN suspended speakers can be installed both indoors and outdoors.
1. Fix the mounting plate to the ceiling with suitable wall plugs
(with 4.5 mm screw).
2. Connect the loudspeaker green wire to the mounting plate earth screw.
CERAMIC
TERMINAL STRIP
CABLE
NYLON CLIP
SUPPORT
NUT
NUT
