26
ENGLISH
SYSTEM MENUS
The System Menus allow the user to control and change parameters that are related to the
system behavior and general operation. It can be accessed by pressing the Sys key in the main
menu (when no Input/Output or System Menu is activated). All System Menus require the Enter
key to be pressed for the selected action.
RECALL - PROGRAM RECALL
The DX 4008 has a non-volatile memory that can store up to 30 different program setups. A
program can be recalled using this menu.
SYSTEM-SETUP MENU: Recall
PROG: 01
NAME: XXXXXXXXXXXX
• PROG - Program Number to be recalled.
• NAME - Program Name. This is read only, the user has no access to them.
STORE - PROGRAM STORE
The DX 4008 has a non-volatile memory that can store up to 30 different program setups. A
program can be stored using this menu. The old program with the same program number will be
replaced. Once the program is stored in the flash memory, it can be recalled at a later time, even
after power down.
SYSTEM-SETUP MENU: Store
PROG: 01
NAME: XXXXXXXXXXXX
• PROG - Program Number for the current data to be stored.
• NAME - Program Name, allows a maximum length of 12 characters.
CONFIG - DEVICE CONFIGURATION
SYSTEM-SETUP MENU: Config
MODE: 2-Way
• MODE - configures the mode of operation.
Mode: Out 1 Out 2 Out 3 Out 4 Out 5 Out 6 Out 7 Out 8
None Any Any Any Any Any Any Any Any
Stereo 2-Way In1 In1 In2 In2 Any Any Any Any
Stereo 3-Way
In1 In1 In1 In2 In2 In2 Any Any
Stereo 4-Way In1 In1 In1 In1 In2 In2 In2 In2
The unit assigns the Inputs 1 and 2 to the corresponding outputs when the Mode of Configuration
is selected. The crossover point parameters like the filter type, cut-off frequency and slope have to
be configured manually in the Xover Menu in each Output menu.
*NOTE: The configuration mode configures the input sources when selected. The user can change
the inputs afterwards if desired.
