RCF DX4008 User Manual

28
ENGLISH
SECURITY - SECURITY LOCKS
The
DX 4008 enables the user to secure the unit and prevent undesired
changes in the setup. In order to switch between the security level the user
must enter the correct password.
SYSTEM-SETUP MENU: Security
MENU: In-Signal
LOCK: No
PASSWORD: XXXX
• MENU - Selects the menu to be locked/unlocked. The options are:
- In-Signal - Input Signal Menu (Level, Polarity, Delay).
- In-EQ - Input EQ Menu.
- In-Name - Input Channel Name Menu
- Out-Signal - Output Signal Menu (Level, Polarity, Delay).
- Out-EQ - Output EQ Menu.
- Out-Xover - Output Crossover Menu.
- Out-Limit - Output Limit Menu.
- Out-Source - Output Source Menu.
- Out-Name - Output Channel Name Menu.
- System - System Menu
• LOCK - Selects to lock (Yes) or unlock (No) the corresponding menu.
• PASSWORD – The password of the DX 4008 is 4 characters long. The user can change it via the
PC application software.
The factory default of a new unit does not require a password.
QUICK REFERENCE
Parameters
Menu
<< menu >>
Field
<< Cursor >>
Min Max Steps Units
Level Signal LEVEL
-40 +15 0,25 dB
Polarity Signal
POL +/-
Delay Signal DELAY
0 24,000 1 21 us step
EQ Number
EQ EQ# 1 6 1
EQ Level
EQ LEVEL -30 +15 0,25 dB
EQ Frequency
EQ FREQ 20 20,000 1 Hz
EQ Bandwidth
EQ BW 0.02 2.50 0.01 Octave
Crossover Low XOver
FTRL Off / Butterworth / Linkwitz-Riley / Bessel
Crossover Low XOver FRQL
20 20,000 1 Hz
Crossover Low XOver
SLPL 6
48 (48kHz)
24 (96kHz)
6 dB/octave
Crossover High XOver
FTRH Off / Butterworth / Linkwitz-Riley / Bessel
Crossover High XOver FRQH
20 20,000 1 Hz
Crossover High XOver
SLPH 6
48 (48kHz)
24 (96kHz)
6 dB/octave
Out Limit Thresh
Limit THRESH -20 +20 0.5 dBu
Out Attack Time
Limit ATTACK 0.3 100 0.1/1 ms
Out Release Time
Limit RELEASE 2 / 4 / 8 / 16 / 32X Attack time
Source Source 1, 2, 3, 4 Off / On
Channel Name Ch-Name
NAME 6 characters
