RCF EVOX 12 - Technical Specifications; Acoustical Specifications; Amplifier;DSP Specifications; Subwoofer Physical Specifications

10
ENGLISH
EVOX 12
ACOUSTICAL
Frequency response 40 Hz ÷ 20 kHz
Maximum sound pressure level 130 dB
Horizontal coverage angle 90°
Vertical coverage angle 30°
Subwoofer transducers 15” (3.0” voice coil)
Satellite transducers 8 x 4” (1.0” voice coil)
AMPLIFIER / DSP
Amplier power (low frequencies) 1000 W (peak)
Amplier power (high frequencies) 400 W (peak)
Input sensitivity (LINE) +4 dBu
Crossover frequency 180 Hz
Protections thermal, RMS
Limiter software limiter
Cooling convective
Operating voltage 115 / 230 V, 50-60 Hz
Inrush current
10,1 A
(According to EN 55013-1: 2009)
SUBWOOFER PHYSICAL
Height 2220 mm (87.4”)
Width 410 mm (16.14”)
Depth 560 mm (22.05”)
Net weight 36.4 kg (80.24 lbs)
Cabinet Birch plywood
SPECIFICATIONS
