RCF S.p.A. thanks you for purchasing this product, which has been designed to
guarantee reliability and high performance.
DESCRIPTION
P series loudspeakers belong to the ‘RCF ACUSTICA’ line for fixed installation.
The model P 3108 can be installed outdoor, with IP 55 protection, if adapted as a sealed box.
This is a two-way loudspeaker providing wide dispersion, high power input rate and efficiency.
Its cabinet is made of UV stabilized plastic resin and its shape allows both single installation and
arrays / clusters (with optional accessories). The front grille is in custom perforated aluminium with
open-cell fibre water repellent woven fabric backing.
Each cabinet is equipped with four M 8 brass inserts and a stainless steel U-Bracket.
The front logo is in aluminium and can be rotated.
Connections to an amplifier are made through a watertight connector.
The high frequency section has a constant directivity horn with a 1” RCF Precision Neodymium
compression driver (1.5” diaphragm).
The low-frequency transducer is a 8” woofer (2.5” voice coil).
SEALED OR VENTED
(BASS-REFLEX) BOX
As factory default, P 3108 is a vented box (bass-
reflex), yet it can be adapted as a sealed box (in order
to get IP 55 protection) by proceeding as follows:
Take off the loudspeaker front
grille by removing the six screws.
Cover the reflex port (the hole)
by using the dedicated plug
(to be fixed with thread-forming
screws).
Re-mount the loudspeaker grille.
•
•
•
SINGLE LOUDSPEAKER INSTALLATION
Loudspeakers are to be install by qualified personnel, respecting all safety standards.
Loudspeakers are to be installed securely.
Make sure the support structure (walls / ceilings) has the necessary mechanical characteristics for
the loudspeaker weight, without the risk of a fall that could damage things or cause an injury.
Use attachments elements suitable for walls / ceilings (e.g. screw anchors for bricks, screw anchors
for concrete, etc.).
A
F
B
C
D
G
E
