Example: for a 3 speakers configuration, this is how the two plates must be positioned:
NOTE: Once chosen the right configuration the Top Plate must be always screwed back on its position, leaving the four
middle holes free.
4. HORIZONTAL HANGING
NOTE: The exact same operations done on the upper side of the speaker must be done on the bottom side too.
BOTTOM VIEW of a 2 SPEAKERS CONFIGURATION
BOTTOM VIEW of a 3 SPEAKERS CONFIGURATION
