5. VERTICAL HANGING
TOP SPEAKER
TOP SPEAKER MIDDLE SPEAKER
LOWER SPEAKER
LOWER SPEAKER
Example: for a 3 speakers vertical configuration, this is how the plates must be positioned:
Example: for a 2 speakers vertical configuration, this is how the plates must be positioned:
NOTE: The exact same operations must be done on both sides of the speaker
NOTE: Once chosen the right configuration the Top Plate must be always screwed back on its position.
B
A
C
B
A
C
B B B
A A A
C C
C
