12
[13] BRIDGE LEDs (A+B) and (C+D). When lit channels A and B (and/or C+D) are bridged (see [11] BRIDGE switches).
[14] STEREO / PARALLEL SWITCH. See the ‘Operation modes’ manual section.
Important: make sure the amplifier is turned off before setting this switch.
SWITCH POSITION MODE FUNCTION
OFF (released)
FOUR INDEPENDENT
CHANNELS
Standard operation: all the four channels are independent
(but in the bridge mode).
Each channel input is only sent to its respective speakers’
and balanced outputs.
ON (pushed) PARALLEL INPUTS A AND
C TO ALL OUTPUTS
Inputs A or C sent to all the speakers’ and balanced
outputs.
[15] BALANCED AUDIO OUTPUT (CH A, CH C). Male XLR connector.
[16] POWER CORD. Connect the power cord only to a mains socket outlet with a protective earthing connection.
