11
ENGLISH
The subwoofer system is equipped with 4 x 100 mm blue rubber wheels on the back
of the cabinet for transportation.
Three aluminium die cast handles with rubber hand-grip are available on each side of the
speaker system.
The outdoor quality, Baltic birch plywood, cabinet is protected with heavy duty, scratch
resistant, polyurea coating.
Two black coated steel bars are provided on the back of the cabinet for fork lift
transportation.
TRANSPORTATION
WARNING: never suspend TT+ speakers by there handles. Handles are intended for
transportation, not for rigging.
WARNING: always make sure that the maximum current requirement does not exceed
the maximum admitted POWERCON current. In case of doubt call the closest RCF service
centre.
MAINS SUPPLY
The system accept mains supply voltage115-230 (+15/-15%) V ~
FUSE F1 VALUE F15 AL 250 V ~
FUSE F2 VALUE T 10 AL 250 V ~
FUSE F3 VALUE T 10 AL 250 V ~
INSTALLATION
WARNING
WARNING
