Section reserved to the
Service
Centre
WARNING The operations described in
this section are for the exclusive use of
the RCF S.p.A. SERVICE CENTRE.
The information given is NOT OF INTEREST to the
user, who need not read it.
Before carrying out the operations described in
this section, it is indispensable to disconnect the
power cable from the AC mains.
Selecting the power supply voltage
1) Remove the upper cover of the unit by unscrewing
the 4 screws on each side and the 2 screws on the
top.
2) Locate the electronic board inside the unit which
holds for the terminals for supply voltage
selection (Fig. 15, page 47).
3) Depending on the supply voltage to be selected,
connect the 4 conductors of the primary circuit of
the power supply transformer to the respective
terminals on the board, as shown in Figure 15 on
page 47.
17
4) Configure jumper “S1”, which is located on the
board for supply voltage selection, as indicated in
the table below.
5) Re-fit the upper cover.
6) Install a fuse in the fuse-holder (9) (Fig. 1, page
42) having suitable capacity for the supply
voltage selected, as indicated on the rear panel of
the amplifier.
POWER SUPPLY CONFIGURATION OF
VOLTAGE “S1” JUMPER
115 Vac Jumper on the terminals
(terminals short-circuited).
230 Vac Terminals without jumper
(terminals open).
