14 15
Visit: www.rdlmeters.com Call: 01803 697 600
3.4 Disconnection
3.4.1 No Remaining Credit
When the prepaid credit expires the timer main contactor will be open, thus disconnecting the
power. To restore power and restart the timed cycle, coins must be inserted.
3.4.2 Reverse Energy Detection
If reverse power is detected above a pre-determined level the display will indicate “RED” (Reverse
Energy Detection). Reverse detection can only be reset via the private mode switch buttons.
3.5 Prepayment Coins
3.5.1 Valid Coins
When a valid coin is inserted, time is credited to the timer and its acceptance is indicated by the
message ‘XXXX Minutes’ being displayed momentarily. The maximum credit is limited to 1440
minutes at which point the display will change to Maximum Reached. An example is shown below:
4. PRIVATE MODE PROGRAMMING
4.1 Programming Method
After REMOVING THE CASH BOX and pressing either of the exposed recessed black private mode
switch buttons, the following 7 parameters can be sequentially viewed/ modified using the RED and
GREEN buttons of the timer.
3.5.2 Maximum Reached
The message “Maximum Reached” is displayed if a coin is inserted that would cause the pre-paid
credit to become greater than Maximum Time hh:mm set.
To display/modify a particular parameter first press either private mode switch buttons upon the
message “Programming” will be displayed. Next press the RED button until the Date and Time are
displayed.
Each press of the GREEN button will increment the value above the cursor.
Each press of the RED button for less than 3 seconds will move the cursor one place through
the programmable setting displayed parameter. To store the new value press the RED button for
greater than 3 seconds, then on releasing the RED button the next parameter for programming will
be displayed. If no buttons are pressed within 10 seconds the display revert to its normal operation
mode without saving the new value.
Example: (shown overleaf)
To change the amount of time credited for each coin inserted the sequence of events will be as
follows:
DISPLAY ACTION
Timer Countdown 00:00:00 Insert value Coin
XXXX Minutes Credited Set time credited to timer
Example 1:
STEP PROGRAMMING SETTINGS
1 DD/MM/YYYY HH:MM Current Date and Time
2 Zero Timer No Yes Manually Zero Timer - No or Yes
3 Token hh:mm Time credited for each token coin inserted
4 Max Time hh:mm Maximum time which can be credited
5
Tournament Mode
No Yes
Select Tournament Mode - No or Yes
6 Operational Mode Meter Timer Select Meter or Timer mode
7 Factory Defaults No Yes
Reset to Factory Defaults excluding kWh
cumulative totals
TIMER MODE TIMER MODE
