240V Fans: 2 pin M12
RS232: RJ45
Relay Specification
Relay 1, EEV, Solid State (PR0029L, 29L-ACF, 33E, 37)
Output Current Rating
3A max, 20mA min
Output Voltage Rating
24-240 VAC
Note: Valve supply and return are limited by internal 24Vac 12VA
transformer
Relay 1, Valve, Mechanical (PR0033E)
Contact Type
SPDT
Contact Rating
10A @ 250Vac (30Vdc) Resistive (CosΦ = 1)
7.5A Inductive (CosΦ = 0.4)
Note: Valve supply and return are limited by internal 24Vac 12VA
transformer
Relay 2, Lights, Standard (PR0029L, 29L-ACF, 33, 33E)
Contact Type
SPDT
Contact Rating
10A @ 250Vac (30Vdc) Resistive (CosΦ = 1)
7.5A Inductive (CosΦ = 0.4)
Peak inrush current (20ms): 20A
Fuse
3.15A, 1500V Breaking Capacity, Type T
NOTE: The lights output is protected by a 3.15A fuse so the lights cannot
draw any more than this under normal running.
Relay 2, Lights, High Inrush (PR0037)
Contact Type
N/O
Contact Rating
16A @ 250Vac Resistive (CosΦ = 1)
Peak inrush current (20ms): 80A
Fuse
3.15A, 1500V Breaking Capacity, Type T
NOTE: The lights output is protected by a 3.15A fuse so the lights cannot
draw any more than this under normal running.
Relay 3, Fans
Contact Type
SPDT
Contact Rating
10A @ 250Vac (30Vdc) Resistive (CosΦ = 1)
7.5A Inductive (CosΦ = 0.4)
Fuse
3.15A, 1500V Breaking Capacity, Type T
Inputs
Probe Input resistance
3.01K Ohms
Probe Input type
PT1000
