Parameter
Description
Green OT Alarm
Over temperature alarm set point when set to green range. This alarm uses the air off
temperature
Yellow Product UT Alarm
Logging probe under temperature alarm set point when set to yellow range.
Yellow Product OT Alarm
Logging probe over temperature alarm set point when set to yellow range.
Red Product UT Alarm
Logging probe under temperature alarm set point when set to red range.
Red Product OT Alarm
Logging probe over temperature alarm set point when set to red range.
Green Product UT Alarm
Logging probe under temperature alarm set point when set to green range.
Green Product OT Alarm
Logging probe over temperature alarm set point when set to green range.
Defrost Start
When defrost mode is set to “Local”, this is the start time for the 1
st
defrost
Defrost Number
When defrost mode is set to “Local”, this is the number of defrosts per day equally spaced
from the start time.
No Defrost Time
If the controller misses a defrost command for any reason, a defrost will initiate after this
time has elapsed from the last defrost. Normally set to 2 hours over the normal defrost
period.
Def. term. temp.
The defrost will terminate when the temperature of the air off probe(s) reaches this value.
Defrost min time
Minimum time that a defrost will use. Defrost can’t terminate until this time has elapsed. If
termination temperature is reached during this period the controller will not continue the
refrigeration cycle until the end of the defrost min period.
Defrost max time
Time period after defrost minimum that defrosts are allowed to terminate.
Drain down time
A period after defrost period to allow the draining of any surplus water.
Recovery time
The valve is switched on at the start of this period to allow the temperature to recover to
the normal operating point. This period also inhibits the OT alarm.
Note that if the air-off temperature is still above the OT alarm setpoint when this period
expires, an immediate OT alarm occurs; there is not a further alarm delay.
Defrost Mode
Allows the user to set the defrost mode: -
Local: Uses the internal parameters (see above)
Remote: Requires a defrost schedule in the front end.
Fans in Def
Allows the fans to run during defrost or not.
Lights Mode
Allows the user to set the lights mode: -
Always off
Always on
Use a local schedule (see below)
Use a remote schedule (Set up in the system front end)
Sun Lights On
When lights mode set to Local, Sunday On Time.
Sun Lights Off
When lights mode set to Local, Sunday Off Time.
Mon Lights On
When lights mode set to Local, Monday On Time.
Mon Lights Off
When lights mode set to Local, Monday Off Time.
Tue Lights On
When lights mode set to Local, Tuesday On Time.
Tue Lights Off
When lights mode set to Local, Tuesday Off Time
Wed Lights On
When lights mode set to Local, Wednesday On Time.
Wed Lights Off
When lights mode set to Local, Wednesday Off Time
Thu Lights On
When lights mode set to Local, Thursday On Time.
Thu Lights Off
When lights mode set to Local, Thursday Off Time.
Fri Lights On
When lights mode set to Local, Friday On Time.
Fri Lights Off
When lights mode set to Local, Friday Off Time.
Sat Lights On
When lights mode set to Local, Saturday On Time.
Sat Lights Off
When lights mode set to Local, Saturday Off Time.
