APOLLO FYM - SPREADER CONTROLLER
11
3. Factory Config
3.1 Machine Options
3.2 Spreader Config
Shaft 1 and Shaft 2 are related to the spinner/beater sensors. The following calibration procedure applies
regardless of the speed output being sensed e.g. Engine RPM, PTO Speed, Shaft Speed, Fan Speed etc,
depending on the particular installation.
In all cases, run the sensed component at a known speed. If necessary measure this speed using a hand-held
tachometer. Note the speed displayed on the "INFO" screen.
The correct Cal. factor = Initial Factor x Displayed Speed
Actual Speed
Default: 1 pulse per rev (PPR)
3.3 Pro-Series Config
This inverts the area cut out status input
Area Cut Out Input
In Work: The Spreader is ON when the cutout input is recognised.
Out Of Work: The Spreader is ON when the cutout input is NOT recognised.
3.4 Channel Setup
To Next Page
