APOLLO FYM - SPREADER CONTROLLER
16
5.2.5 RDS ‘Satspeed’ Interface / NMEA VTG Input
No calibration is necessary.
5.3 Pre-Start
See Pre-Start Setup guide in the Operators Manual, section 2.4.
6. Alarms
6.1 Setting the Alarm thresholds
1. Press to select the "SETUP" menu.
2. Select the "ALARMS SETUP" button at the base of the screen.
6.1.1 Low / High RPM Alarm
From the RPM SETUP screen, you can also set a minimum and maximum RPM at which an alarm is triggered.
Set as necessary.
Default = 0 (Alarms Off)
6.1.2 LOW Weight Alarm
This can be used as a reminder that the hopper is nearly empty.
Default = 0 (Alarms Off)
7. General PF Setup
Please refer to the "Data Logging and Transfer" manual (ref. RDS Pt. No. S/DC/500-10-573).
