Re WG251 SKB-C RESMART User Manual

Re S.p.A. WG251 SKB-C RESMART
22/11/12 19/25
(Functions that can be associated to the F
n
key: all except F.50, F.51, F.52 and F.90)
Range: 0=Off: F
n
key is not active, 1=On: F
n
key is active.
Default value: 1=On
F.10 - Servo Center offset
This function is enabled only if the system is in MAN status and it is used to change the stop position of
the Servo Center.
Range: 0÷100 (value expressed in percentage in relation to the maximum stroke)
Default value: 50
F.11 - Last status memo
The function is used to select whether to store the device operating status before switch off.
Range: 0=Off: at power up the device status is MAN, 1=On: at power up the device status is the same
as before it was switched off.
Default value: 0=Off
Warning: the function cannot be activated if the function F.15=1 (Remote controls=On);
activating the Remote controls function, the Last status memo function is disabled (Off)
automatically
F.12 - Servo Center at power up
This function is used to select whether the actuator performs the Servo Center automatically when the
regulator is powered on.
Range: 0=Off: when the device is powered on the system does not perform the Servo Center, 1=On:
when the device is powered on the system performs the Servo Center.
Default value: 0=Off
F.14 - MAN motor inversion
This function is used to invert the rotation direction of the motor when the actuator is positioned
manually (in MAN) from the operating window with the + or – keys (see pages 10-11).
Range: 0=Off: the actuator movement direction is standard, 1=On: the actuator movement direction is
inverted.
Default value: 0=Off
F.15 - Remote controls
This function enables and disables the use of the remote controls to manage the status changes of the
system (from AUTO to MAN and vice versa).
Range:
0=Off: status changes, AUTO/MAN and vice versa, and the Servo Center can be controlled
only with MWG10
1=On: status changes, AUTO/MAN and vice versa, can be controlled only by using remote
controls while the Servo Centre can be controlled both by MWG10 or remote controls.
2: enables the remote controls from keyboard: the automatic key enables the remote controls,
the manual key disables the remote controls.
Default value: 0=Off
F.20 - Sensor selection
This function is used to select whether to use both sensors or just one. This function allows you to
switch from an edge guide regulation (set value 1 or 2) to a centre guide (set value 3), without changing
any connection or recalibrating the system.
