Rea®Clematis®
3.4Adjustingthebrakeeffect
A
C
B
ThedistanceAbetweenthepinBandthetireC
shouldbemax.2mm.
3.4.1Userbrake—adjustment
Toattainthecorrectbrakingeffect,thebrakepinshould
pressintothetirewhenyouapplythebrake.Thebrakemay
thereforerequiredepthadjustment.
WARNING!
Riskofreducedbrakeeffect
–Incorrectsettingoruseofthebrakereduces
thebrakingeffect.
B
A
C
Tool:5mmAllenkey
1.LoosenthescrewA.
2.Movethebraketotherequiredposition.
3.Re-tightenthescrewA.
CAUTION!
Riskoftrappingngers
–Becarefulnottotrapyourngersbetweenthe
brakepinBandrearwheelC.
3.4.2Drumbrake—adjustments
1.
A
AdjustthebrakeeffectwiththeadjustmentnutAon
thewire.
2.
B
B
Whenthedesiredbrakeeffectisachieved,xatethe
brakewirewiththexationnutB.
WARNING!
Riskofinjury
Poorbrakeeffect
–Checkthebrakeeffectaftermountingor
adjustingthebrake.
101580314-C

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the REA Clematis and is the answer not in the manual?

REA Clematis Specifications

General IconGeneral
Seat Depth42 - 50 cm
Max User Weight135 kg
FoldableYes
Wheel Size24 inches
Seat Width39 / 44 / 49 cm
