Rea®Clematis®
5.
B
A
Re-mounttheseatplateBontheseatframeand
tightenthescrewsA.
5mmallenkey
6.
F
G
PlacethepommelFintheattachmentandtightenthe
handwheelG.
2.9MountingtheDripstand
Therodofthedripstandmustalwaysbeplacedin
averticalposition,i.eina90degreeangletothe
ground,nomatterthepositionofthebackrestor
thewheelchair .

90°
90°
1.
A
B
MounttheholderforthedripstandAontheneckrest
holderandtightenthescrewB.
allenkey5mm
2.
C
D
E
MounttheleverC,thewashersDandtheholderwith
thedripstandEintheattachmentandtightenthelever.
