Assembly
2.7Mountingthechassisextender
1.
A
B
B
LoosenthescrewsAandthenutsB.
2.
C
RemovethecastorattachmentsC.
3.
D
D
E
E
MountthechassisextenderDinthechassistubesE
andtightenthescrews.
4.
A
B
B
C
Re-mountthecastorattachmentCandtightenthe
screwsAandthenutsB.
2.8Mountingthepommel
1.
A
B
LoosenthescrewsAandremovetheseatplateB.
5mmallenkey
2.
B
C
B
TurntheseatplateBupsidedownandmountthetee
nutsC.
Hammer
3.
D
E
B
TurntheseatplateBbackagainandmountthe
attachmentforthepommelD.
4.AttachthescrewsE.
5mmallenkey
1580314-C
7
