ITEM
NO.
PART NUMBER DESCRIPTION
1 210-00030 Drip Tray- single Cup
2 210-00031 GRID- SINGLE CUP
3 230-00004 Flip down grid sub-assembly
4 210-00004 Bezel
5 B256A COVER, USB PORT
6 230-00001 Reservoir sub-assembly
7 210-00052 Float guide
8 230-00021 Float assembly
9 280-00001 VALVE, DW15 CHECK
10 210-00051 Reservoir
11 280-00004 Valve, 3-way 24vac
12 280-00005 VALVE, 1/8 X 1/8 BARB CHECK
13 310-00000 Air Pump, 6vdc micro
14 230-00019 Relief valve sub-assembly
15 230-00010 Mechanism cover
16 230-00016 Probe holder assembly
17 310-00002 Pump
18 344-00002 FLOWMETER
19 230-00013 Tank assembly-single cup
20 348-00004 Triac assembly - Single cup
21 280-00007 VALVE, 24VAC WATER INLET
22 348-00003 USB PCB
23 343-00009 Power Cord- 16-3 SJT NEMA 5-15P
24 343-00017 Harness-Single cup heater
25 359-00031 FITTING, ASSY, 1/4 FL X 3/4 HS, SS
26 356-00004 DAMPER, LINEAR
27 230-00028 Kit, Single Cup drip tray & gr
28 210-00235 Cap, Molded inlet valve
29 230-00029 Kit, Inlet fitting and flare washer
30 210-00230 Reservoir rotating lid-NSF
31 210-00233 Reservoir stationary cover
32 380-00068 LABEL, WARNING, HOT LIQUID
33 348-00006 Control-Single Cup Brewer
34 348-00008 PCB- Single Cup display
35 345-00007 LCD display- capacitive 3.5"
36 362-00000 TUBING, 1/8" ID X 1/4" OD
37 362-00001 TUBING, 3/16" ID X 5/16" OD
38 210-00101 Plug- drain tube
39 230-00030 Kit, Single Cup drain cover &
40 230-00031 Kit, capsule seals
41 230-00032 Kit, Bypass seal, ball, spring
42 346-00003 Transformer, 40va 120/24 vac
43 356-00009 Standoff-0.156 dia hole x 3/16
44 354-00003 CLAMP, TO-220 HEAT SINK
45 230-00015 Capsule holder sub-assembly
