SYMPTOM
CAUSE
AND
REMEDY
24],
Noisy
VOLUME
control
A)
Defective
VR902
Replace.
B)
Defective
capacitor
C506
or
C903
Replace
the
defective
capacitor(s).
25l, SIGNAL
meter
not
functioning
26l,
TUNING
meter not
functioning
A)
Defective
meter
Replace
meter.
B) Defective
capacitor
C402
Replace
the
capacitor.
C) ln
case of FM
reception,
lC2O1,
TH201
or
V R202
defective.
Replace
the
defective component(s).
D)
ln
case of AM
reception,
VR401
defective
Replace,
A)
Defective
meter
Replace
the
meter.
B)
Resistor
R226
defective
Replace
the resistor.
27)
LO Fl
Lter
has
no
effect
28) Hl
FlLter
has no
effect
A)
Defective
switch
SWB
Replace
the
switch.
B) Defective
capacitor
Cg14
Replace
the
capacitor.
A)
Defective
switch
SW7
Replace
the
switch.
B) Defective
resistor
R919
or capacitor
C913
Replace
the
defective
component(s).
