RTL8773B Motherboard User Guide
8
·Copyright 2019 Realtek Semiconductor Corporation.
All Rights Reserved.
KEYS&LEDs control jumper
J6
1
3 5 7
9
2
4 6
8
10
11
14
13
12
Pin Description Pin Description Pin Description
1 KEY0 2 M1_1
3 KEY1 4 M1_2
5 KEY2 6 M1_4
7 KEY3 8 M1_5
9 KEY4 10 M4_1
11 KEY5 12 M3_0 17 L
ED9
13 KEY6 14 M3_1 18 L
ED10
15 KEY7 16 M2_2 19 L
ED11
18 19
17
15
16
KEYs&LEDs control jumper
J3
1
3 5
7
9
2
4 6 8
10
11
12
Pin Description Pin Description Pin Description
1 LED6 2 M2_4
3 LED5 4 M2_3
5 LED4 6 M1_3
7 LED3 8 M2_1 13 KEY3
9 LED2 10 M1_0 14 KEY2
11 LED1 12 M0_1 15 KEY1
14 1513
