Realtek RTL8852AE - RF Exposure Considerations and Antenna Usage

RTL8852AE User’s Manual
2.5 Trace antenna designs
Not applicable.
2.6 RF exposure considerations
This equipment complies with FCC mobile radiation exposure limits set
forth for an uncontrolled environment. This equipment should be installed
and operated with a minimum distance of 20cm between the radiator &
your body. If the module is installed in a portable host, a separate SAR
evaluation is required to confirm compliance with relevant FCC portable
RF exposure rules.
2.7 Antennas
The following antennas have been certified for use with this module; antennas of the
same type with equal or lower gain may also be used with this module. The antenna
must be installed such that 20 cm can be maintained between the antenna and users.
Approved antenna(s) list :(Mobile)
Antenna
Set
Chain NO. Brand Model
Antenna
Gain
(dBi)
Frequency
range
(GHz)
Antenna
Type
Connector
Type
1
Chain 0 LYNwave ALA110-222050-300011
3.5 2.4~2.5
PIFA i-pex(MHF)
5 5.15~5.85
Chain 1 LYNwave ALA110-222050-300011
3.5 2.4~2.5
PIFA i-pex(MHF)
5 5.15~5.85
2
Chain 0 PSA RFDPA171320EMLB301
3.14 2.4~2.5
Dipole i-pex(MHF)
5 5.15~5.85
Chain 1 PSA RFDPA171320EMLB301
3.14 2.4~2.5
Dipole i-pex(MHF)
5 5.15~5.85
For SAR (Portable)
Brand Model
Antenna
Gain
(dBi)
Frequency
range
(GHz)
Antenna
Type
Connector
Type
REALTEK RTK-ANT-0006
3.5 2.4~2.5 PIFA i-pex(MHF)
5 5.15~5.85 PIFA i-pex(MHF)
