REC Alpha 72 Series - Table of Contents; Contents; List of Figures


REC Installation Manual - REC Alpha  Series - IEC  /
Rev A  . Ref: NE
CONTENTS
CONTENTS 
List of figures 
INTRODUCTION 
How to use this manual 
Your responsibility as an installer 
Support 
Liability disclaimer 
Limited warranty 
SAFETY MEASURES 
Safety in the working area 
PANEL HANDLING 
CHOOSING AN INSTALLATION LOCATION 
ELECTRICAL INSTALLATION 
Electrical requirements 
MECHANICAL INSTALLATION 
Fire guidelines 
Orientation 
PANEL INSTALLATION 
Rail specifications 
Mounting methods: Clamping with rails parallel to the short side 
Mounting methods: Slide in systems 
Mounting methods: Mounting holes 
Drainage holes 
CONNECTIONS AND CONNECTORS 
CABLE MANAGEMENT 
PANEL MAINTENANCE 
RECYCLING 
DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC EQUIPMENT 
PANEL CHARACTERISTICS 
Technical Properties: REC Alpha  Series 
ANNEX : INSTALLATIONS ON WATER PLATFORMS 
ANNEX : INSTALLATIONS USING MODULE LEVEL POWER ELECTRONICS 
EC DECLARATION OF CONFORMITY 
DOCUMENT HISTORY 
LIST OF FIGURES
Fig. : Clamp specifications: Mid-clamps 
Fig. : Clamping of panels with rails parallel to short side 
Fig. : Clamping zones for panels with rails parallel to short side 
Fig. : Mounting holes: REC Alpha  Series 
Fig. : Device specifications for mounting holes: REC Alpha  Series 
Fig.  Mounting hole installation example: REC Alpha  Series 
Fig. : Drainage and grounding holes 
Fig. : Connector mating matrix 
Fig. : Minimum cable bend radius 
Fig. : WEEE symbol 
Fig. : Panel dimensions: REC Alpha  Series 
Fig. : MLPE device installation zones 
