RECO SensorLine RM-DPC Micro FP - Parameter List

RM-DPC Micro FP Documentation
RDN 10000531 9 13.05.2013
5.4 Parameter list
Parameter
Text on the display Explanation Factory setting Setting range
01
01 Contr. type
Device function dP-control.
dP-control,
dP-monitor
02
02 dP min
∆p min switch point
700 Pa
150 Pa ...
(dP max - 50 Pa)
1
03
03 dP max
∆p max switch point
900 Pa
200 Pa ...
(dP max alarm - 50 Pa)
2
04
04 dP min alarm
∆p min alarm switch point
0
3
0
3
, 100 Pa ...
(dP max alarm - 50 Pa)
2
05
05 dP max alarm
∆p max alarm switch point
1800 Pa 0
3
, 500 ... dP range
4
06
06 Timer start
Timer for relay output
5
0
3
0
3
... 240 h
07
07 Timer unit
Time unit of the timer min s, min
08
08 Timer period
Time period of the timer 10 s 0
3
... 500 (s / min)
6
09
09 Service hrs.
Service hours alarm
7
0
3
0
3
, 500 hrs .... 25,000 hrs
10
10 Maintenance
acknowledge ?
Resets the service hours coun-
ter
No No, yes
11
11 dP source
Internal / External sensor Internal Internal, external
12
12 dP range
Full scale output
5000 Pa
8
or 10000 Pa
9
1000 Pa ... 5000 Pa
8
or 1000 Pa ... 10000 Pa
9
13
13 Current range
4-20 mA / 0-20 mA 4-20 mA 4-20 mA, 0-20 mA
14
14 dP attenuat.
Alarm / Control delay 2 s 1 s ... 30 s
15
15 dP unit
Unit of the displayed
differential pressure
Pa
Pa, mbar, hPa,
inch H
2
O
16
16 Default set.
Loads factory setting No No, yes
17
17 Language
Display text language DE DE, EN, FR, ES
1
Maximum value of the setting range = configured ∆p max switch point (see Parameter 03 "dP max") minus 50 Pa.
2
Maximum value of the setting range = configured ∆p max switch point (see Parameter 05 "dP max alarm") minus 50 Pa.
3
0 = Function deactivated.
4
Configured measuring range of the sensor (see Parameter 12 "dP range")
5
See point

on page 5
6
Depends on the setting of Parameter 07 "Timer unit".
7
The service hours counter runs when the differential pressure ∆p is greater than 200 Pa and the parameter 09 "Service hrs." has
not been configured to 0.
8
Applies to the RM-DPC 5000 Micro FP – the full scale output can be configured in 500 Pa increments.
9
Applies to the RM-DPC 10000 Micro FP – the full scale output is configurable in 500 Pa increments for the range
1000 Pa ... 5000 Pa, and continuously configurable for the range 5000 Pa ... 10000 Pa.
