RECO SensorLine RM-DPC Micro FP - Timer Function (Parameters 06, 07, 08); Self-Monitoring; Troubleshooting

RM-DPC Micro FP Documentation
RDN 10000531 12 13.05.2013
6.3 Timer function (Parameters 06, 07, 08)
In addition to the differential pressure dependent two-position control, the timer function also makes it
possible to carry out time-controlled forced cleaning. The timer works independently of other device func-
tions.
After the time configured under "Timer start" (Parameter 06) elapses, relay contact 12, 13 closes and
contact 11, 12 opens (see point

on page 5). After the time configured under "Timer period" (Parameter
08) elapses with the configured "Timer unit" (Parameter 07), relay contact 12, 13 opens and contact 11,
12 closes.
6.4 Self-monitoring
If all relay outputs are inactive (contacts 12, 13 / 15, 16 / 18, 19 are closed), then the RM-DPC Micro FP
differential pressure monitor is either
switched off or
defective.
7 Troubleshooting
Error
Possible causes
Recommended action
The "ON" LED is not lit.
No mains voltage
Check power feed
Device fuse is defective
Replace fuse
EMERGENCY STOP activated
Check EMERGENCY STOP
No differential pressure display
Differential pressure measure-
ment hoses are incorrectly at-
tached.
Reattach the hoses to the con-
necting piece of the
RM-DPC Micro FP.
Differential pressure display error
Hose connection error

Drain hoses. Clean joints be-
tween hose connections and
the filter casing with com-
pressed air (only towards the
filter, never towards the sen-
sor).
 Fit the hoses so there are no
kinks.
 Check the hose connections in
the device for water, kinks, etc.
"Alarm" LED flashing
∆p alarm
Refer to the service instructions
of the filter.
"Service" LED flashing
The configured number of service
hours has elapsed.
Perform filter maintenance. Then
configure Parameter 10 to "Yes"
(acknowledge the service mes-
sage).
