Table 5 lists UMP weights and lengths and Table 6 lists pump shut-off pressures.
NOTE: The weights and lengths listed below are approximate values and will vary due to manufacturing
tolerances.
The optional trapper intake screen is available as a field installed accessory. Trapper options will increase the
length of the UMP by 3.3 inches (83 mm). For installation instructions, see Red Jacket installation instructions
#051-256-1. For models with floating suction adapter, add 2-3/8 inches (59 mm) and 4 pounds (1.8 kg).
Table 5. UMP Model Dimensions
Franklin Motor
(Use these lengths for
UMPs with end view A
shown in Figure 1)
Faradyne Motor
(Use these lengths for
UMPs with end view B
shown in Figure 1) Weight
UMP Model HP in. mm in. mm lb. kg
UMP33U1, AGP33R1 1/3 15-1/2 390 15-3/8 391 24 11.0
UMP75U1, AGUMP75S1 3/4 17-3/4 447 17-5/8 448 28 12.7
UMP75U3-3, AGUMP75S3-3 3/4 20 507 19-7/8 505 30.5 13.9
UMP75U17-3, AGUMP75U17-3 3/4 19-1/4 489 19 483 28 12.7
UMP150U1, AGUMP150S1 1-1/2 20-1/2 519 20-5/8 524 34 15.5
X3P150U1, X3AGUMP150S1 1-1/2 21-1/4 540 21-1/2 546 35 15.8
UMP150U3-3, AGUMP150S3-3 1-1/2 22-1/4 565 22-1/4 565 34 15.5
X4P150U3, X4GUMP150S3 1-1/2 22-3/4 576 22-7/8 581 35 15.9
UMP150U17-3, AGUMP150S17-3 1-1/2 21 532 21-1/4 540 31 14.1
X4P150U17, X4AGUMP150S17 1-1/2 21-1/2 547 21-3/4 552 32 14.5
UMP200U1-3, AGUMP200S1-3,
UMPL200U1-3, AGUMPL200S1-3
2 24-1/4 618 24-5/8 626 36 16.3
UMP200U3-4, AGUMP200S3-4 2 26 660 26-1/4 667 38 17.2
UMP200U17-4, AGUMP200S17-4 2 23-3/4 600 23-3/4 603 36 16.3
Table 6. Approximate Pump Shut-Off Pressures
UMP Model Approximate Shut-Off Pressure
AGUMP33S1, UMP33R1 25 psi (172 kPa) .74 SG @ 60°F (15°C)
AGUMP75S1, UMP75U1 28 psi (193 kPa) .74 SG @ 60°F (15°C)
AGUMP150S1, UMP150U1 30 psi (207 kPa) .74 SG @ 60°F (15°C)
X3AGUMP150S1, X3UMP150U1 43 psi (297 kPa) .74 SG @ 60°F (15°C)
AGUMP75S3-3, UMP75U3-3 30 psi (207 kPa) .74 SG @ 60°F (15°C)
AGUMP75S17-3, UMP75U17-3 29 psi (200 kPa) .74 SG @ 60°F (15°C)
AGUMP150S3-3, UMP150U3-3 32 psi (220 kPa) .74 SG @ 60°F (15°C)
AGUMP150S17-3, UMP150U17-3 32 psi (220 kPa) .74 SG @ 60°F (15°C)
