Electrical Data and Service Information
Table 2 and Table 3 show pump electrical service requirements for UMPs with end views A and B, respectively.
Table 4 shows pump electrical service requirements for EN 15268 UMPs with end view B.
Table 2. Electrical Service Information (For Umps Containing A Franklin Motor With End View A) - For STPs With UL,
cUL, 03ATEX0237289X, 04ATEX0330285X, 06ATEX6050X, ANZEX 04.3005X Or POCC 05.B02160 Markings
Required power supply rating for 60 Hz, 1 phase pumps is 208 - 230 Vac. For 50 Hz, 1 phase pumps, required rating is 220 - 240 Vac. For
3 phase pumps, required rating is 380 - 415 Vac.
UMP Model No. HP Hz PH
Voltage
Fluctuation
Range
Max.
Load
Amps
Locked
Rotor
Amps
Winding Resistance (Ohms)
Capacitor Kit (µF)
or Heaters (KXX)Min. Max.
Black-
Orange
Red-
Orange Black-Red
AGUMP33S1,
UMP33U1
1/3 60 1 200 250 4.0 13 7.7 - 9.4 17.4 - 21.2 25 - 30.7 144-224-5 (17.5)
AGUMP75S1,
UMP75U1
3/4 60 1 200 250 6.5 25 2.9 - 3.6 14.9 - 18.2 17.7 - 21.9 410164-001 (17.5)
AGUMP150S1,
UMP150U1
1-1/2 60 1 200 250 10.5 37 2.0 - 2.5 11.6 - 14.2 13.5 - 16.8 410164-002 (25)
X3AGUMP150S1,
X3UMP150U1
1/1/2 60 1 200 250 10.5 37 2.0 - 2.5 11.6 - 14.2 13.5 - 16.8 410164-002 (25)
AGUMP200S1-3,
UMP200U1-3
2 60 1 200 250 11.4 46 1.4 - 1.7 2.5 - 3.2 3.8 - 5 410164-003 (40)
AGUMP75S3-3,
UMP75U3-3
3/4 50 1 200 250 5.8 17 3.6 - 4.5 20.4 - 25 23.9 - 29.6 410164-001 (17.5)
AGUMP150S3-3,
UMP150U3-3
1-1/2 50 1 200 250 10 28 2.5 - 3.1 11.5 - 14 13.9 - 17.2 410164-002 (25)
X4AGUMP150S3,
X4UMP150U3
1-1/2 50 1 200 250 10 28 2.5 - 3.1 11.5 - 14 13.9 - 17.2 410164-002 (25)
AGUMP200S3-4,
UMP200U3-4
2 50 1 200 250 11 37 1.9 - 2.4 3.1 - 3.9 5.0 - 6.3 410164-003 (40)
AGUMP75S17-3,
UMP75U17-3
3/4 50 3 342 457 2.2 8 25.8- 32.4 25.8- 32.4 25.8- 32.4 K26
AGUMP150S17-3,
UMP150U17-3
1-1/2 50 3 342 457 3.8 15 13.1 - 16.4 13.1 - 16.4 13.1 - 16.4 K33
X4AGUMP150S17,
X4UMP150U17
1-1/2 50 3 342 457 3.8 15 13.1 - 16.4 13.1 - 16.4 13.1 - 16.4 K33
AGUMP200S17-4,
UMP200U17-4
2 50 3 342 457 5.0 22 9.3 - 11.6 9.3 - 11.6 9.3 - 11.6 K37
