Red Kite Push Me Pace i - Parts Identification and Assembly; Parts List; Assembly Instructions

Front bumper
Raincover (not shown))
Apron (not shown)
Parts List Ctd
Front
wheels*2
2 in 1
Seat
Rear
wheels*2
2
3
Wheel release
4
Parts List
Canopy
Handle bar
Bumper release button
BBrake
BBasket
Adjustable foot rest
Liner
Foot rest
Swivel wheel lock
5 point harness
Rear wheels
Adjustable
handle button
Frame
Lock
hook
1a 1b 1c
Front wheels
Front bumper
To open the frame
1. Release the lock clip on the side of the frame (fig 1a), lift the handle upwards (fig 1b) until it
locks in place. Fig 1c.
WARNING Ensure that all the locking devices are engaged before use.
Assembly Instructions
To attach the wheels
2. Push the metal stems of the front wheels upwards into the front wheel holders until they click in
place. Fig 2. Pull gently to ensure the wheel is locked in place.
3. To remove the wheel, press in the top button and pull the wheel out. Fig 3.
4. Insert the metal stem of the rear wheel into the end of the brake unit until it clicks in place. Pull
gently to ensure the wheel is locked in place. To remove the rear wheel, press the button on the
bottom of the brake unit and pull the wheel out. Fig 4.
Release
button
Adaptors*2
Car seat
