3-DRAWINGS AND TECHNICAL SPECIFICATIONS
TECHNICAL CHARACTERISTICS COMPACT 18 HYDRO COMPACT 24 HYDRO
Type of fuel: Pellets Pellets
Max nominal output power (total/water):
18.1 kw / 15566 kcal / 17 kw H
2
O/ 14620
kcal
24.5 kW / 21,070 kcal / 22.1 kW / 19,006
kcal
Minimum output power:
4.3 kw / 3,698 kcal / 3.8 kw H
2
O/ 3,268
kcal
4.3 kW / 3,698 kcal / 3.8 kW / 3,268 kcal
Eciency at Max 93,8% 90,2%
Eciency at Min 88,5% 88,5%
Temperature of exhaust smoke at Max 120 °C 150°C
Temperature of exhaust smoke at Min 65 °C 65°C
Particulate/OGC / Nox (13%O
2
)
29.3 mg/Nm
3
- 2.7 mg/Nm
3 -
135.2 mg/
Nm
3
(13% O
2
)
17.8 mg/Nm
3
- 0.1 mg/Nm
3 -
132 mg/
Nm
3
(13% O
2
)
CO at 13% O
2
at Min and at Max 0,021% – 0,017% 0,021 - 0,010%
CO
2
at Min and at Max 5,9% - 9,2% 5,9 - 9,0%
Recommended draught at Max power 0.10 mbar - 10 Pa 0.10 mbar - 10 Pa
Recommended draught at Min power 0.05 mbar - 5 Pa 0.05 mbar - 5 Pa
Mass of smoke at Min and at Max 4.9 - 12.7 g/sec 4.9 - 17.5 g/sec
Hopper capacity 100 litres 100 litres
Type of pellet fuel
Pellet diameter 6-8 mm and size 5/30
mm
Pellet diameter 6-8 mm and size 5/30
mm
Pellet hourly consumption Min ~ 1 kg/h* - Max ~ 3.6 kg/h* Min ~ 1 kg/h* - Max ~ 4.8 kg/h*
Autonomy At min ~ 68 h* - At max ~ 19 h* At min ~ 68 h* - At max ~ 15 h*
Water content 25 litres 25 litres
Maximum operating pressure 3 bar 3 bar
Combustion air inlet External diameter 80 mm External diameter 80 mm
Smoke outlet External diameter 100 mm External diameter 100 mm
Electrical power consumption Max 430 W - Med. 180 W Max 430 W - Med. 180 W
Supply voltage and frequency 230 Volt / 50 Hz 230 Volt / 50 Hz
Net weight 200 kg 200 kg
Weight with packaging 220 kg 220 kg
* Data that may vary depending on the type of pellets used.
The boiler is a continuous combustion appliance.
Tested according to EN 303-5 in compliance with Directive 89/106/EEC (Construction Products).
