47
12-MAINTENANCE AND CLEANING
CLEAN THE EXCHANGER AND THE UNDERGRATE SPACE EVERY 2/3 DAYS.
Cleaning the exchanger and the undergrate space is a simple operation but very important for always maintaining performance as
declared.
Therefore we recommend cleaning the internal exchanger every 2-3 days, performing these simple operations in sequence:
• Activate the “CLEANING” function – when the boiler is switched of press - menu, select“Settings”, with the <> arrows select
“Cleaning”, conrm with “Menu”, activate cleaning “ON” by pressing the +- keys. This procedure activates the smoke extraction fan
on maximum power to expel the soot that is dislodged when the exchanger is cleaned.
• Clean the pipe unit – Using the cold handle supplied shake the rods placed under the cover vigorously 5-6 times. This will remove
any soot that has deposited on the exchanger smoke ducts during normal boiler operation.
• Disable the “CLEANING” function - this function is automatically disabled after two minutes. If one needs to stop this function in
advance press the “Esc” key.
• Clean the smoke conveyor compartment (g.2) - The boiler is tted with a removable ash pan designed to collect any soot and
ash build-up.
• Once cleaning is complete close the cover and ash pan.
If such cleaning is not done every 2-3 days the boiler could go into alarm caused by ash clogging after several hours
of operation.
Technical Dept. - All rights reserved - Reproduction is prohibited
ASH PAN
Figure 1
Figure 2
