13 - MAINTENANCE AND CLEANING
CLEANING THE LOWER COMPARTMENT OF GARDENIA/MARGHERITA AND ORCHIDEA/PRIMULA STOVES
Clean around the brazier “A”. Remove the 4 screws and the cap “B” and using the nozzle of a vacuum cleaner, remove any ash and soot that
may have built up in the lower exchanger indicated by the arrow.
CLEANING THE LOWER COMPARTMENT OF THE DALIA STOVE
Clean around the brazier “A”. Remove the 2 screws and the cap “L”. Then remove the plate “H” by removing the two screws and using the
nozzle of a vacuum cleaner, remove any ash and soot that may have built up in the lower exchanger indicated by the arrow.
CLEANING THE SMOKE DUCT AND GENERAL CHECKS
Clean the smoke extractor duct, especially around the “T” joints, bends and any horizontal sections.
For information on cleaning the ue, contact a chimney sweep.
Check the seal of the ceramic bre gaskets on the door of the stove. If necessary, order new replacement seals from the retailer or contact
an authorized service centre to carry out this task.
CAUTION:
The frequency with which the smoke outlet system is cleaned depends on the use of the boiler and the type of
installation.
We recommend relying on an authorised service centre for end-of-season cleaning and maintenance, as they will
carry out all of the previously mentioned work and inspect the stove components.
CLEANING THE LOWER COMPARTMENT
OF THE GARDENIA/MARGHERITA AND
ORCHIDEA/PRIMULA STOVES
"T" FITTING
