RED ONE User Manual

Nov 12 2008 Copyright RED Digital Cinema
71
Pin:
Signal
Description
Direction
1
LEFT+
Line output, left channel
Out
2
GROUND
Camera Ground
-
3
LEFT-
Line output, left channel
Out
4
RIGHT+
Line output, right channel
Out
5
RIGHT-
Line output, right channel
Out
Line Output Connectors
Note: Cameras shipped prior to Sept 15 2008 do not provide Camera Ground on Pin 2
Headphone Audio Output
A 3.5mm stereo phone jack provides two channels of adjustable level audio to headphones.
The camera’s four audio channels may be monitored in user selectable pairs (either channels 1
& 2 or 3 & 4 or a quad mix of both pairs) based on the ‘Headphone MIX’ parameter.
The headphone output signal level may be adjusted via the HEADPHONE menu.
Pin:
Signal
Description
Direction
TIP
LEFT
Left channel audio
Out
RING
RIGHT
Right channel audio
Out
SLEEVE
GND
Camera ground
--
Headphone Output Connector
Note: Cameras shipped prior to Sept 15 2008 should use high impedance headphones.
USB-2 Master (Host)
This port is currently not enabled.
Note: The USB-2 Master port may be used as a convenient power source for a LED-based
USB based script light.
USB-2 Slave (Device)
This port is currently not enabled.

RED ONE Specifications

General

Frame Rates	1-120 fps
Lens Mount	PL Mount
Recording Format	REDCODE RAW
Sensor Size	24.4mm x 13.7mm
Resolution (pixels)	4520 x 2540
Video Output	HD-SDI
Weight	10 lbs (body only)
Recording Media	CF card
