Genlock Input
A single DIN 1.0/2.3 coaxial connector accepts a Tri-Level Sync signal for video genlocking.
When operating at 23.98, 24.00, 25.00 or 29.97 Project Time Bases, set the genlock signal gen-
erator to SMPTE 274 progressive scan format, at the same frame rate as the project TIME BASE.
Do not use PsF or interlaced signals.
Using an Ambient ACL202CT, set dip switches as follows: D = down, U = up, R = right, L = left
Note: After changing any of the above dip switch settings, power cycle the ACL202CT unit.
Frame Rate 23.98 fps 1D, 2U, 3D, 4D, 5U, 6U, 7U, AR, BR
24.00 fps 1D, 2U, 3U, 4D, 5U, 6U, 7U, AR, BR
25.00 fps 1U, 2U, 3U, 4D, 5U, 6U, 7U, AR, BR
29.97 fps 1D, 2D, 3U, 4D, 5U, 6U, 7U, AR, BR
When operating at 50.00 or 59.94 Project Time Bases, set the genlock signal generator to
SMPTE 296 progressive scan format, at the same frame rate as the project TIME BASE.
Using an Ambient ACL202CT, set dip switches as follows: D= down, U = up, R = right, L = left
Frame Rate 50.00 fps - settings not verified at this time -
59.94 fps 1D, 2D, 3U, 4U, 5U, 6D, 7U, AR, BR
Connect the camera Genlock input to the ACL202CT VIDEO/WORD output using a BNC cable.
