RED ONE User Manual

Nov 12 2008 Copyright RED Digital Cinema
73
In record, the Program output provides two independent outputs of 1280 x 720p 10-bit 4:2:2
progressive scan video, at 59.94 or 50.00 Hz.
In playback, if PLAYBACK is set to 720p, the Program output provides two independent outputs
of 1280 x 720p 10-bit 4:2:2 progressive scan video, at 59.94 or 50.00 Hz.
If PLAYBACK is set to 1080p, the Program output provides a 1920 x 1080p 10-bit 4:4:4 RGB
progressive scan video signal at 23.98, 24.00, 25.00, or 29.97 Hz.
Note: the Program HD-SDI output provides 4 channels of embedded audio plus timecode.
Note: When in Varispeed, the Program output will be blanked.
Note: RED ONE outputs progressive scan video, it does not support the 1080PsF format.
Note: If recording in ANA (anamorphic) mode, the Program HD-SDI output will represent
the image in the final 2.40:1 aspect ratio. Only use this mode with 2:1 anamorphic lenses.
Preview HD-SDI
A single DIN 1.0/2.3 connector labeled PVW provides a high definition video preview output.
Pin:
Signal
Description
Direction
Center
HD-SDI
SMPTE-292M HD-SDI
Out
Shield/Screen
GROUND
Camera ground
--
Preview HD-SDI Output
Note: If PREVIEW type is set to MENUS (DVI) the PVW output is disabled.
In record, the Preview output provides a 1280 x 720p 10-bit 4:2:2 progressive scan video, at
59.94 or 50.00 Hz.
In playback, if PLAYBACK is set to 720p, the Preview output provides a 1280 x 720p 10-bit 4:2:2
progressive scan video, at 59.94 or 50.00 Hz.
If PLAYBACK is set to 1080p, the Preview output provides a 1920 x 1080p 10-bit 4:2:2 progres-
sive scan video signal at 23.98, 24.00, 25.00, or 29.97 Hz.

RED ONE Specifications

General

Frame Rates	1-120 fps
Lens Mount	PL Mount
Recording Format	REDCODE RAW
Sensor Size	24.4mm x 13.7mm
Resolution (pixels)	4520 x 2540
Video Output	HD-SDI
Weight	10 lbs (body only)
Recording Media	CF card
