3 USER GUIDE
Navigation
The Left/Right buttons are used to navigate the pages on the centre of the screen.
The Up/Down buttons are used to navigate through options found on other pages or to
cycle through devices on the Home Page when a Distribution Box is connected.
The Left/Right and Up/Down functions are indicated on the screen.
Soft Keys
The Soft Keys functions will be indicated by and icon and these functions will change
depending on the screen
Power Button Function
Pushing the Power Button ONCE will open a Power Button instruction
dialogue and allow switching between Storage and Touring modes.
Pushing the Power Button TWICE will invoke the ‘Master Switch’
function, when a Distribution Box is installed.
This function switches a defined set of devices and can be customised,
by the installer, to user specifications.
HOLDING the Power Button will put the screen into Standby mode.
Pushing any button will wake the screen up again. When the system is
set to ‘Storage Mode’ only the Power Button will wake the display up.
Notification Bar
HOLD
Push
Push x2
Bluetooth
®
Connected
Master Switch Invoked
Fault Indication
Load Disconnect Invoked
Storage Mode Selected
Alarm Notification
24
