VENT-FREE GAS WALL
HEATER
OWNER’S OPERATION AND
INSTALLATION MANUAL
INFRARED MODELS
IWH10NLTC
IWH16NLTC
IWH26NLTC
PFS
®
US
WARNING: If the information in this manual is not
followed exactly, a re or explosion may result causing
property damage, personal injury or loss of life.
Do not store or use gasoline or other ammable va-
pors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use any
phone in your building.
Immediately call your gas supplier from a neighbors
phone. Follow the gas suppliers instructions.
If you cannot reach your gas supplier, call the re
department.
Installation and service must be performed by a quali-
ed installer, service agency or the gas supplier.
WARNING: This appliance is equipped for Natural and
Propane gas. Field conversion is not permitted other than
between natural or propane gases.
Questions, problems, missing parts?
Before returning to your retailer, call our customer service department at
1-800-229-5647, 8:00 am - 4:30 pm EST, Monday through Friday

Questions and Answers

  • A
    Alexander MillerAug 20, 2025
    What to do if there is spark at ODS/pilot but no ignition in my ReddyHeater?
    • J
      Jenna MartinezAug 20, 2025
      If you press the ignitor button on your ReddyHeater and there's a spark at the ODS/pilot, but no ignition occurs, try the following: * Ensure the gas supply is on and the equipment shutoff valve is open. * Fully press the control knob while pressing the ignitor button. * Hold down the control knob and repeat the igniting operation to remove air from the gas lines. * Clean the ODS/pilot or replace the ODS/pilot assembly. * Check the inlet gas pressure or replace the inlet gas regulator. * Ensure the control knob is in the PILOT position. * Contact your local propane/LP gas company if the gas supply is depleted.
  • R
    Rebecca LawsonAug 22, 2025
    Why does the pilot light go out when I release the control knob on my ReddyHeater?
    • D
      Dana WashingtonAug 22, 2025
      If the ODS/pilot light of your ReddyHeater lights, but the flame goes out when you release the control knob, here’s what you can do: 1. Make sure you are pressing the control knob fully. 2. After the ODS/pilot lights, keep the control knob pressed in for 30 seconds. 3. Ensure the equipment shutoff valve is fully open. 4. Hand tighten the thermocouple connection at the control valve until it is snug, then tighten it an additional 1/4 turn. 5. If the pilot flame isn't touching the thermocouple, contact your local gas company or clean/replace the ODS/pilot assembly. 6. Replace the thermocouple if it is damaged. 7. Replace the control valve if it is damaged.
  • R
    robert15Aug 25, 2025
    What to do if my ReddyHeater shuts off in use?
    • W
      Wesley GriffithAug 25, 2025
      If your ReddyHeater shuts off during use, and the ODS (Oxygen Depletion Sensor) is operating, it could be due to: * Insufficient fresh air. Try opening a window or door for ventilation. * Low line pressure. Contact your local gas supplier. * A partially clogged ODS/pilot. Try cleaning the ODS/pilot.
  • H
    Hailey MatthewsAug 26, 2025
    How to fix no spark at ODS/pilot on my ReddyHeater?
    • A
      Ashley HawkinsAug 26, 2025
      If you press the ignitor button on your ReddyHeater and there is no spark at the ODS/pilot, here are some potential solutions: * Replace the pilot assembly if the ignitor electrode is positioned wrong or broken. * Replace the ignitor cable if it is not connected, pinched, wet, or broken. * Free the ignitor cable if it is pinched and keep it dry. * Replace the piezo ignitor if it is bad.
  • I
    Ian LewisAug 27, 2025
    What to do if burner does not light after ODS/pilot is lit on ReddyHeater?
    • R
      ryan39Aug 28, 2025
      If your ReddyHeater burner(s) doesn't light after the ODS/pilot is lit, it might be due to: * A clogged burner orifice. Try cleaning or replacing it. * A burner orifice diameter that is too small. Replace the burner orifice. * Low inlet gas pressure. Contact your local gas supplier.
  • N
    Nicholas AndersonAug 30, 2025
    Why does my ReddyHeater smell like gas when it is off?
    • J
      Jesus LopezAug 30, 2025
      If you notice a gas odor even when the control knob of your ReddyHeater is in the OFF position: * Locate and correct any gas leaks. * Replace the control valve if it is defective.
  • S
    Scott JacobsAug 31, 2025
    Why is there a delayed ignition of burner(s) in my ReddyHeater?
    • E
      Erica ChanAug 31, 2025
      If the burner(s) on your ReddyHeater experiences delayed ignition, it could be due to: * Manifold pressure that is too low; in this case, contact your local gas supplier. * A clogged burner orifice; try cleaning or replacing the burner orifice.
  • C
    Christopher PhillipsSep 2, 2025
    Why is my ReddyHeater burner backfiring?
    • A
      Amber GonzalezSep 2, 2025
      If your ReddyHeater burner backfires during combustion, it could be due to: * A clogged or damaged burner orifice. Try cleaning or replacing it. * A damaged burner. Replace the burner. * A damaged gas regulator. Replace the gas regulator.
  • D
    David KingSep 4, 2025
    Why is there a high yellow flame during burner combustion in my ReddyHeater?
    • M
      megansmithSep 4, 2025
      If you notice a high yellow flame during burner combustion in your ReddyHeater, consider the following: * There may not be enough air. Check the burner for dirt and debris, and clean it if necessary. * The gas regulator may be defective. Replace the gas regulator. * The inlet gas pressure may be too low. Contact your local gas supplier.
  • L
    lperezSep 6, 2025
    Why does my ReddyHeater smell like gas during combustion?
    • R
      Rebecca HaleSep 6, 2025
      If you notice a gas odor during combustion in your ReddyHeater: * Take apart the gas tubing and remove any foreign matter between the control valve and burner. * Locate and correct all gas leaks.

Summary

SAFETY

QUALIFIED INSTALLING AGENCY

Outlines the qualifications and responsibilities of agencies installing the heater.

PREPARING FOR INSTALLATION

AIR FOR COMBUSTION AND VENTILATION

INSTALLATION

GAS SELECTION

Step-by-step instructions for converting the heater between propane and natural gas.

CONNECTING TO GAS SUPPLY

Detailed instructions for safely connecting the heater to the gas line.

CHECKING GAS CONNECTIONS

Procedures for verifying gas connections are leak-free using a detection fluid.

PRESSURE TESTING GAS CONNECTIONS

Methods for testing the gas supply piping system for leaks.

OPERATION

LIGHTING INSTRUCTIONS

Step-by-step guide for safely igniting the pilot light and main burner.

INSPECTING HEATER

CARE AND MAINTENANCE

TROUBLESHOOTING

SERVICE HINTS
