1.0 TECHNICAL SPECIFICATIONS
Model
7516
Working width 1.60 mtr (5’4”)
Working depth Up to 400 mm (16”)
Tractor speed @ 500 rev’s at PTO
Hole spacing 65 mm (2-1/2”)
Hole spacing 130mm( 5”)
Hole spacing 195mm(7-1/2”)
Up to 0.70 km/h (0.45 mph)
Up to 1.40 km/h (0.90 mph)
Up to 2.10 km/h (1.35 mph)
PTO speed Up to 500 rpm
Weight 1130 Kg (2490 lbs)
Hole spacing side-to-side 129 mm (5”) @ 24 mm (1”) holes
65 mm (2.5”)@ 12 mm (1/2”) holes
Hole spacing in driving direction 50 – 195 mm ( 2 - 7-1/2”)
Recommended tractor size 45 HP with lift capacity of minimum 1350 Kg
( 3000 lbs)
Capacity (maximum)
Spacing 65 mm (2-1/2”)
Spacing 130mm (5 “)
Spacing 195mm (7-1/2”)
Up to 1120 sq.mtr (10200 sq ft)/ hour
Up to 2240 sq.mtr (20400 sq.ft)/ hour
Up to 3360 sq.mtr (30600 sq.ft)/ hour
Shipping dimensions 1780 x 1000 x 1500 mm
(71”x 40”x 60”)
Maximum tine size Solid 25 x 400 mm (1”x 16”)
Hollow 32 x 300 mm (1-1/4”x 12”)
Slip clutch setting PTO Maximum 800 Nm. (7080 lb.inch.)
Three point linkage 3- point CAT 1-2
Transmission oil Life time grease EP 00
Lubrication grease EP 2
Standard items Set solid tines 18/300 (3/4”x 12”) with adapters
Front and rear roller
3- shuttle gearbox
Toolbox with combi tool
