1.0 TECHNICAL SPECIFICATIONS
Model
7526
Working width 2.60 mtr (8’8”)
Working depth Up to 400 mm (16”)
Tractor speed @ 500 rev’s at PTO
Hole spacing 65 mm (2-1/2”)
Hole spacing 130mm( 5”)
Hole spacing 195mm(7-1/2”)
Up to 0.70 km/h (0.45 mph)
Up to 1.40 km/h (0.90 mph)
Up to 2.10 km/h (1.35 mph)
PTO speed Up to 500 rpm
Weight 1595 Kg (3510 lbs)
Hole spacing side-to-side 129 mm (5”) @ 24 mm (1”) holes
65 mm (2.5”)@ 12 mm (1/2”) holes
Hole spacing in driving direction 50 – 195 mm ( 2 - 7-1/2”)
Recommended tractor size 65 HP with lift capacity of minimum 1900 Kg
( 4200 lbs)
Capacity (maximum)
Spacing 65 mm (2-1/2”)
Spacing 130mm (5 “)
Spacing 195mm (7-1/2”)
Up to 1820 sq.mtr (16600 sq ft)/ hour
Up to 3620 sq.mtr (33200 sq.ft)/ hour
Up to 5460 sq.mtr (49800 sq.ft)/ hour
Shipping dimensions 2780 x 1000 x 1500 mm
(111”x 40”x 60”)
Maximum tine size Solid 24 x 400 mm (1”x 16”)
Hollow 32 x 300 mm (1-1/4”x 12”)
Slip clutch setting PTO Maximum 800 Nm. (7080 lb.inch.)
Three point linkage 3- point CAT 2
Transmission oil Life time grease EPL 00
Lubrication grease EP 2
Standard items Set solid tines 18x300 (3/4”x12”)
Front and rear roller
3- shuttle gearbox
Toolbox with combi tool
PTO shaft
