Fuel system
Remove the 6 screws holding the handle
halves together.
Carefully lift off the left (upper) handle half.
Make sure that the recoil spring for the
catch for the twistable handle does not fl y
out.
Inspect the rubber sleeves (E) and the
O-ring (F) for wear and damage.
Replace any faulty parts.
Inspect the rubber sleeves (E) and the
O-ring (F) for wear and damage.
Replace any faulty parts.
Lubricate the O-ring with a little grease
when fi tting it so that the handle can twist
easier.
Prise up the locking tab and pull off the
handle.
Prise up the locking tab (D) using a small
screwdriver.
Then pull off the twistable handle from the
handle mounting.
