Fuel system
Lift off the lock preventing unintentional
full throttle (A).
Remove the catch (B) for the twistable
handle and its spring (C).
Remove the throttle lever (D).
Note how this recoil spring is tensioned.
Prise off the ignition switch (E) using a
small screwdriver.
Assemble the throttle handle in the
reverse order as set out for dismantling.
Note the following:
Make sure that the short-circuit cable is
properly pressed into the handle half so
that it is jammed in place.
