GZ500
Recommended bar lengths, inch/cm 13-20/33-51
Pitch, inch/mm 0.325/8.25
Thickness of drive links, inch/mm 0.058/1.5, 0.050/1.3
Type of drive sprocket/number of teeth Spur/7
Saw chain speed at 133% of maximum engine power
speed, ft/s / m/s
75.5/23.1
Accessories
Recommended cutting equipment
A specific chainsaw model has to be evaluated with the
cutting equipment to be recommended and fulfill the
requirements in ANSI B175.1-2012 (Internal Combustion
Engine-Powered Hand-Held Chainsaws - Safety and
Environmental Requirements) and Canadian Standards
CSA Z62.1-15 (Chainsaws) and CSA Z62.3-11 (R2016)
(Chainsaw kickback).
Chainsaw model RedMax GZ500 meet the safety
requirements in ANSI B175.1-2012 and Canadian
Standards Association CSA Z62.1-15 (Chainsaws) and
CSA Z62.3-11 (R2016) (Chainsaw kickback), when
equipped with the below listed saw chain and guide bar
combination(s).
Note: Other chainsaw models may not meet the
kickback requirements when equipped with the listed
guide bar and saw chain combinations.
We recommend only to use the listed guide bar and saw
chain combinations.
Kickback and guide bar nose radius
For sprocket nose bars the nose radius is specified by
the number of teeth, such as 10T. For solid guide bars
the nose radius is specified by the dimension of the
nose radius. For a given guide bar length, you can use a
guide bar with smaller nose radius than given.
Guide bar Saw chain
Length, in Pitch, in Gauge, in Max. nose ra-
dius
Type Low kickback Length, drive
links (no.)
13 0.325 0.050 10T RedMax
SP33G
RedMax H30
Yes 56
15 64
16 66
18 72
20 78/80
*
13 0.325 0.058 10T RedMax H25 Yes 56
15 64
16 66
18 72
20 12T 78/80
*
1513 - 001 - 25.06.2020 33
