15
5. DISPLAYING THE TIMERS
 Press the TIMER A button (19) will display the set time of the Timer A,
the “TIMER A” sign will also flash on the LCD panel.
 Press the TIMER B button (18) will display the set time of the Timer B,
the “TIMER B” sign will also flash on the LCD panel.
6. SETTING THE TIMERS
Timer A
1. Press the TIMER A button (19) until the “TIMER A” sign flashes.
2. Press the UP button (13) to select adjustment for hour; press the UP
button (13) for a longer while to increase the hour, or rotate the
TUNING knob (23) to increase or decrease the hour.
3. Press the DOWN button (15) to select adjustment for hour; press the
DOWN button (15) for a longer while to increase the hour, or rotate the
TUNING knob (23) to increase or decrease the hour.
4. When the desired time reading is reached, press the TIMER A button
(19) again to confirm, the clock is now set.
Timer B
 Press the TIMER B button (18) until the “TIMER A” sign flashes.
 The other steps as the same as for Timer A, items 2 – 4 above.
H. OTHER FUNCTIONS
1. BACKLIGHT FOR LCD PANEL
 Press the LIGHT button (4) once, the backlight for the LCD panel will
be on for 8 seconds.
 Press the LIGHT button (4) for 2 seconds or longer, the backlight for
the LCD panel will be on always, until the LIGHT button (4) is pressed
again.
