5
See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual. IMPORTANT: Some small parts
m
ay have been preattached. If a part is not in the hardware kit, check to see if it has been preattached.
M6 Washer (21)
M8 Washer (20)
M8 x 80mm Screw (13)
M8 x 63mm Bolt (16)
M8 x 38mm Bolt (18)
M6 x 35mm Screw (15)
M10 x 190mm Bolt (14)
M8 Locknut (24)
M10 Locknut (19)
M4 x 12mm Self-tapping Screw (17)
PART IDENTIFICATION CHART
