Reebok Crosstrainer C3.1 - Page 33

C3.1-503
M4 Nut
M4 Mutter
1
C3.1-504
Tension Bracket Adjustment Base
Riemenspannerbasis
2
C3.1-505
Tension pulley axle
Riemenspannerachse
1
C3.1-506
Ø 20X16 Washer
Ø 20x16 U-Scheibe
2
C3.1-507
6300Z Bearing
6300Z Kugellager
2
C3.1-508
M10 Nut
M10 Mutter
1
C3.1-509
M12X94 Bolt
M12x94 Bolzen
1
C3.1-510
M12X7 Nut
M12x7 Mutter
1
C3.1-511
Magnet bracket base
Magnethalterung
1
C3.1-512
M6X10 Screw
M6x10 Schraube
2
C3.1-601
Ø 10x26 Washer
Ø 10x26 U-Scheibe
2
C3.1-602
Magnet Bracket Spring
Feder - Magnethalterung
1
C3.1-603
Magnet Bracket
Magnethalter
1
C3.1-604
M6 Nut
M6 Mutter
1
C3.1-605
M6X40 Bolt
M 6x40 Schraube
1
C3.1-606
Motor
Motor
1
C3.1-701
Foot Plate Tube-Left
Pedalstange links
1
C3.1-702
Foot Plate Tube-Right
Pedalstange rechts
1
C3.1-703
Foot Plate-Left
Pedal links
1
C3.1-704
Foot plate tube Fix Bolt
Pedalstangen Befestigungsschraube
2
C3.1-705
Ø 10 Washer
Ø 10 U-Scheibe
4
C3.1-706
M10 Nut
M10 Mutter
2
C3.1-707
Foot Plate-Right
Pedal rechts
1
C3.1-708
Ø 42.5 Bearing Holder Washer
Ø 42.5 Sicherungsring
2
C3.1-709
2300Z Bearing
2300 Z Kugellager
2
C3.1-710
Rear Foot Plate Tube rear Cover-Upper
Hintere Pedalstangenabdeckung oben
2
C3.1-711
Rear Foot Plate Tube rear Cover-Lower
Hintere Pedalstangenabdeckung unten
2
C3.1-712
Front Foot Plate Tube front Cover-Left
Vordere Pedalstangenabdeckung links
2
C3.1-713
Front Foot Plate Tube front Cover-Right
Vordere Pedalstangenabdeckung rechts
2
C3.1-714
Foot Plate Fix Bolt
Pedal Befestigungsschraube
2
C3.1-715
Foot Plate fix Knob
Pedalbefestigungshandrad
2
C3.1-801
Overlay
Displaybeschriftung
1
C3.1-802
Console housing -Upper
Computergehäuse Oberteil
1
C3.1-803
Battery Cap
Batteriekappe
1
C3.1-804
Upright upper Cover -Rear
Frontstützengehäuse hinten
1
C3.1-805
Upright upper Cover-Front
Frontstützengehäuse vorne
1
C3.1-806
Hand Pulse Sensor Wire -upper
Handpulssensorkabel oben
2
C3.1-808
Seven Pin Wire
7 poliges Kabel
1
C3.1-809
Console housing - lower
Computergehäuse Unterteil
1
C3.1-810
PC Board
Computer
1
