Reebok Fusion User Manual

Fusion TREADMILL
7
PARTS LIST
Description Qty. Order No.
400
Base Frame Assembly
401 Motor Hood 1
REV11301-401
402 DC Motor 1
REV11301-402
403 Motor Bracket 1
REV11301-403
404 Driving Belt 1
REV11301-404
405 Motor Cover – Bottom 1
REV11301-405
406 Control Board 1
REV11301-406
407 Shaft 1
REV11301-407
408 Triangle Plastic Cap - Upper 2
REV11301-408
409 Shaft Cover 4
REV11301-409
410 Triangle Plastic Cap - Bottom 2
REV11301-410
411 Triangle Plastic Cap Base 2
REV11301-411
412 Incline Motor Steel Tube 1
REV11301-412
413 Incline Motor Holder Bushing 1
REV11301-413
414 Incline Motor 1
REV11301-414
415 Steel Bushing 2
REV11301-415
.
500
Motor Assembly
501 Base Frame 1
REV11301-501
502 Foot Plate 1
REV11301-502
503 Rubber Cushion 4
REV11301-503
504 Rear Caster Cover-Left 1
REV11301-504
505
∮50 Rear Caster
2
REV11301-505
506 Rear Caster Cover-Right 1
REV11301-506
600.
Running Deck Assembly
601 400X2512 Running Belt 1
REV11301-601
602 Side Rail 2
REV11301-602
603 Side Rail End Cap-Left 1
REV11301-603
604 Side Rail End Cap-Right 1
REV11301-604
605 597X1100X14 Running Deck 1
REV11301-605
606
∮30X2 Running Deck Mat
8
REV11301-606
607 Side Rail Holder 8
REV11301-607
700
Deck Frame Assembly
701 Main Frame 1
REV11301-701
702 Front Roller 1
REV11301-702

Reebok Fusion Specifications

General

Display	LCD
Folding	Yes
Running Area	140 x 46 cm
Weight Capacity	120 kg
Running Surface	140 x 46 cm
Heart Rate Monitoring	Pulse sensors
Dimensions	178 x 76 x 132 cm
Weight	76 kg
