Reebok Fusion User Manual

Fusion TREADMILL
8
PARTS LIST
No. Description Qty. Order No.
703 Front Roller Shaft 1
REV11301-703
704 Fold Up Support Tube 1
REV11301-704
705 Small Wheel 1
REV11301-705
706 Rear Roller 1
REV11301-706
707 Rear Roller Shaft 1
REV11301 -707
708 Rear Caster 2
REV11301 -708
800
Fastening
801
∮3.5X14 Screw
10
REV11301-801
802
∮3X10 Screw
4
REV11301 -802
803
∮3X14 Screw
1
REV11301 -803
804
∮4X14 Screw
31
REV11301 -804
805 M8X43 Allen Head Cap Bolt 8
REV11301 -805
806
∮8 Washer
20
REV11301 -806
807
∮4X40 Screw
2
REV11301 -807
808 M6X20 Screw 4
REV11301 -808
809
∮4X19 Screw
18
REV11301 -809
810 M6X45 Allen Head Cap Screw 3
REV11301 -810
811
∮6 Washer
3
REV11301 -811
812 M10X42 Allen Head Square Bolt 1
REV11301 -812
813
∮10 Washer
4
REV11301 -813
814 M10 Nut 4
REV11301 -814
815 Washer 3
REV11301-815
816 M5X18 Screw 5
REV11301 -816
817 M6X15 Screw 2
REV11301 -817
818 M10X66 Allen Head Cap Bolt 1
REV11301 -818
819 M8X30 Allen Head Screw 4
REV11301 -819
820 M5 Screw 1
REV11301 -820
821
∮Washer
1
REV11301 -821
822 M10X30 Allen Head Bolt 1
REV11301 -822
823 M8 Nut 5
REV11301 -823
824 M8X47 Square Bolt 1
REV11301-824
825 M8X85 Motor Adjustment Bolt 1
REV11301 -825
826
∮35X6 Spring Washer
2
REV11301 -826
827
∮25X12 PU Mat
1
REV11301 -827
828 M8X12 Screw 2
REV11301 -828
829
∮8 Spring Washer
2
REV11301 -829

Reebok Fusion Specifications

General

Display	LCD
Folding	Yes
Running Area	140 x 46 cm
Weight Capacity	120 kg
Running Surface	140 x 46 cm
Heart Rate Monitoring	Pulse sensors
Dimensions	178 x 76 x 132 cm
Weight	76 kg
