6
1.
Identify the Front Stabilizer (2), which has
Wheels (17) attached. Attach the Front Stabilizer to
the Frame (1) with two M10 x 85mm Button Screws
(56).
2. Tighten the two Leveling Feet (29) into the bottom
of the Rear Stabilizer (3).
Attach the Rear Stabilizer (3) to the Frame (1) with
two M10 x 85mm Button Screws (56).
1
56
3
29
29
56
1
2
1
2
17
To make assembly easier, read the information
on page 5 before you begin assembling the
exercise cycle.
