Feat ur es
• Built-in laser pointer identi es target area
• User selectable °F or °C
• 12:1 distance to spot size ratio
• Digitally adjustable emissivity
• Max, Min, Average and Differential readings
• Backlit display
• High and low alarms
• Dustproof and Drop tested
• Trigger lock for continuous monitoring
• Low battery indication and auto shut off
Included
• Carrying Case
• Battery
Specificat ions
Temperature Range: -31 to 1202°F (-35 to 650°C)
Accuracy: ≥32°F (0°C):±3.6°F (1.8°C) or
±1.8% rdg., whichever is greater
<32°F (0°C:±3.6°F+0.1°F (1.8°C+0.1°C)/rdg.
Resolution: 0.1°F (0.1°C)
Optical Resolution (D:S): 12:1
Spectral Response: 8 to 14µm
Emissivity: 0.1 to 1.0 (Adjustable)
Response Time: 250ms
Backlit Display: Yes
Display Hold: Yes
High/Low Alarms: Yes
Alarm Indicators: LED (High: Red, Low: Blue)
continued...
